SMA562LE G/W
ActiveAmerican Opto Plus LED
DISP 14SEG 0.56 DUAL RED 10DIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SMA562LE G/W
ActiveAmerican Opto Plus LED
DISP 14SEG 0.56 DUAL RED 10DIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SMA562LE G/W |
|---|---|
| Color | Red |
| Common Pin | Common Anode |
| Current - Test | 20 mA |
| Digit/Alpha Size | 14.2 mm |
| Digit/Alpha Size | 0.56 in |
| Display Type | 7-Segment |
| Millicandela Rating | 25 mcd |
| Number of Characters | 2 |
| Package / Case | 10-DIP |
| Power Dissipation (Max) [Max] | 70 mW |
| Size / Dimension [x] | 0.748 in |
| Size / Dimension [x] | 19 mm |
| Size / Dimension [y] | 0.984 in |
| Size / Dimension [y] | 25 mm |
| Size / Dimension [z] | 0.151 in |
| Size / Dimension [z] | 3.85 mm |
| Voltage - Forward (Vf) (Typ) | 2 V |
| Wavelength - Peak | 632 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 3.68 | |
| 10 | $ 2.76 | |||
| 100 | $ 2.30 | |||
| 500 | $ 1.61 | |||
| 750 | $ 1.47 | |||
Description
General part information
SMA562 Series
Display Modules - LED Character and Numeric Red 7-Segment 2 Character Common Anode 2V 20mA 0.748" H x 0.984" W x 0.151" D (19.00mm x 25.00mm x 3.85mm) 10-DIP
Documents
Technical documentation and resources
