26PCBFD2G

Active

Honeywell Sensing and Productivity Solutions

SENSOR 5PSIC .05V

Search across all available documentation for this part.

Active

Honeywell Sensing and Productivity Solutions

SENSOR 5PSIC .05V

Technical Specifications

Parameters and characteristics for this part

Part	Port Size	Port Size	Port Size	Operating Pressure	Operating Pressure	Output [Min]	Output [Max]	Output	Features	Package / Case	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Port Style	Voltage - Supply [Min]	Voltage - Supply [Max]	Pressure Type	Termination Style	Applications	Output Type	Maximum Pressure	Maximum Pressure	Accuracy	Output
Honeywell Sensing and Productivity Solutions 26PCBKT
Honeywell Sensing and Productivity Solutions 26PCBFG5G	6.35 mm	0.25 "	Male Tube	34.47 kPa	5 PSI	0 mV	150 mV	10V	Temperature Compensated	4-SIP	Through Hole	85 °C	-40 °C	Barbless	2.5 V	16 V	Gauge	PC Pin	Board Mount	Wheatstone Bridge	20 PSI	137.9 kPa
Honeywell Sensing and Productivity Solutions 26PCBFG5G38	6.35 mm	0.25 "	Male Tube	34.47 kPa	5 PSI	0 mV	50 mV		Temperature Compensated	4-SIP Module	Through Hole	85 °C	-40 °C	Barbless	2.5 V	16 V	Gauge	PC Pin		Wheatstone Bridge	20 PSI	137.9 kPa	0.5 %	10 V
Honeywell Sensing and Productivity Solutions 26PCBFG2G	3.56 mm	0.14 "		34.47 kPa	5 PSI	0 mV	50 mV		Temperature Compensated	4-SIP Module	Through Hole	85 °C	-40 °C	Barbed	2.5 V	16 V	Compound	PC Pin	Board Mount	Wheatstone Bridge			0.5 %	10 V
Honeywell Sensing and Productivity Solutions 26PCBFD2G				34.47 kPa	5 PSI	0 mV	50 mV		Temperature Compensated	4-SIP Module	Through Hole	85 °C	-40 °C	No Port	2.5 V	16 V	Compound	PC Pin	Board Mount	Wheatstone Bridge			0.5 %	10 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Pressure Sensor ±5PSI (±34.47kPa) Compound 0 mV ~ 50 mV (10V) 4-SIP Module
