Technical Specifications
Parameters and characteristics for this part
| Specification | TMT 50115 |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | cULus, CE, cURus, CB |
| Current - Output (Max) [Max] | 3.4 A |
| Efficiency | 83 % |
| Features | Universal Input |
| Load Regulation | 50 mV |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 50 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 4-DIP Module |
| Power (Watts) | 51 W |
| Size / Dimension [x] | 89 mm |
| Size / Dimension [x] | 3.5 in |
| Size / Dimension [y] | 2.52 " |
| Size / Dimension [y] | 64 mm |
| Size / Dimension [z] | 32 mm |
| Size / Dimension [z] | 1.26 in |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC, 370 VDC |
| Voltage - Input [Min] | 85 VAC, 85 VDC |
| Voltage - Output 1 | 15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
TMT 50 Series
Enclosed AC DC Converters 1 Output 15V 3.4A 85 ~ 264 VAC, 85 ~ 370 VDC Input
