RU42S-M-A110

Active

IDEC

RELAY PLUG-IN 4PDT 3A 120VAC ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

IDEC

RELAY PLUG-IN 4PDT 3A 120VAC ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Part	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Must Operate Voltage	Contact Rating (Current)	Coil Voltage	Release Time	Termination Style	Must Release Voltage	Load - Max Switching	Coil Current	Coil Resistance	Operate Time	Switching Voltage [Max]	Relay Type	Contact Form	Coil Type	Approval Agency	Mounting Type	Features
IDEC RU42S-M-A110	-55 °C	60 °C	Gold (Au) Silver Nickel (AgNi)	96 VAC	3 A	120 VAC	20 ms	Plug In	36 VAC	300 W 2500 VA	7.1 mA	4.55 kOhms	20 ms	30 VDC 250 VAC	General Purpose	4PDT (4 Form C)	Non Latching	CE CSA cURus TUV	Socketable
IDEC RU42S-MD-D12	-55 °C	60 °C	Gold (Au) Silver Nickel (AgNi)	9.6 VDC	3 A	12 VDC	20 ms	Plug In 14 Pin	1.2 VDC	300 W 2500 VA	80 mA	160 Ohms	20 ms	30 VDC 250 VAC	General Purpose	4PDT (4 Form C)	Non Latching	CE CSA cURus TUV	Socketable	Diode Lighted Indicator Mechanical Indicator
IDEC RU42S-MD-D110	-55 °C	60 °C	Gold (Au) Silver Nickel (AgNi)	88 VDC	3 A	110 VDC	20 ms	Plug In 14 Pin	11 VDC	300 W 2500 VA	8.9 mA	12.1 kOhms	20 ms	30 VDC 250 VAC	General Purpose	4PDT (4 Form C)	Non Latching	CE CSA cURus TUV	Socketable	Diode Lighted Indicator Mechanical Indicator

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay 4PDT (4 Form C) 120VAC Coil Socketable
