LS7166B-S

Active

LSI/CSI

IC BCD COUNTR QUAD 24BIT 20SOIC

Search across all available documentation for this part.

Active

LSI/CSI

IC BCD COUNTR QUAD 24BIT 20SOIC

Technical Specifications

Parameters and characteristics for this part

Specification	LS7166B-S

Count Rate	40 MHz
Direction	Up, Down
Logic Type	Binary Counter, BCD Counter, Divide-by-N
Mounting Type	Surface Mount
Number of Bits per Element	24
Number of Elements	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Package / Case	20-SOIC
Package / Case [y]	0.295 in
Package / Case [y]	7.5 mm
Supplier Device Package	20-SOIC
Trigger Type	Negative, Positive
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	3 V

Part	Package / Case	Package / Case [y]	Package / Case [y]	Voltage - Supply [Max]	Voltage - Supply [Min]	Number of Elements	Trigger Type	Count Rate	Supplier Device Package	Direction	Number of Bits per Element	Logic Type	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]
LSI/CSI LS7166B-S	20-SOIC	0.295 in	7.5 mm	5.5 V	3 V	1	Negative Positive	40 MHz	20-SOIC	Down Up	24	BCD Counter Binary Counter Divide-by-N	Surface Mount	-40 °C	125 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Counter IC BCD Counter, Binary Counter, Divide-by-N 1 Element 24 Bit Positive, Negative 20-SOIC
