2SC0115T2A0-12

Active

Power Integrations

IGBT DRIVER, 14.5V-15.5V, MODULE ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Power Integrations

IGBT DRIVER, 14.5V-15.5V, MODULE ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	2SC0115T2A0-12

Channel Type	Independent
Current - Peak Output (Source, Sink)	15 A, 15 A
Driven Configuration	High-Side, Low-Side
Gate Type	IGBT
High Side Voltage - Max (Bootstrap) [Max]	1200 V
Mounting Type	Surface Mount
Number of Drivers	2
Operating Temperature [Max]	105 °C
Operating Temperature [Min]	-40 °C
Package / Case	Module
Rise / Fall Time (Typ) [custom]	12 ns
Rise / Fall Time (Typ) [custom]	6 ns
Supplier Device Package	Module
Voltage - Supply [Max]	15.5 V
Voltage - Supply [Min]	14.5 V

Part	Supplier Device Package	Voltage - Supply [Min]	Voltage - Supply [Max]	Driven Configuration	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Number of Drivers	Current - Peak Output (Source, Sink)	Gate Type	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	High Side Voltage - Max (Bootstrap) [Max]	Channel Type	Package / Case
Power Integrations 2SC0115T2A0-12	Module	14.5 V	15.5 V	High-Side Low-Side	12 ns	6 ns	2	15 A 15 A	IGBT	105 °C	-40 °C	Surface Mount	1200 V	Independent	Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

High-Side or Low-Side Gate Driver IC Module
