1007C

Murata Power Solutions Inc.

TUBE ROHS COMPLIANT: YES

Search across all available documentation for this part.

Murata Power Solutions Inc.

TUBE ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	1007C

ET (Volt-Time)	310 VµS
Height - Seated (Max) [Max]	0.64 in
Height - Seated (Max) [Max]	16.25 mm
Inductance	7.4 mH
Mounting Type	Through Hole
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Size / Dimension [x]	15.06 mm, 0.593 in
Size / Dimension [y]	0.593 in, 15.06 mm
Transformer Type	General Purpose
Turns Ratio - Primary:Secondary [custom]	1
Turns Ratio - Primary:Secondary [custom]	1
Turns Ratio - Primary:Secondary [custom]	1

Part	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Transformer Type	ET (Volt-Time)	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [y]	Inductance	Mounting Type	Turns Ratio - Primary:Secondary [custom]	Turns Ratio - Primary:Secondary [custom]	Turns Ratio - Primary:Secondary [custom]	Weight	Weight	Turns Ratio - Primary:Secondary [custom]
Murata Power Solutions Inc. 1009C	0.64 in	16.25 mm	General Purpose	550 VµS	70 °C	0.593 in 15.06 mm	0.593 in 15.06 mm	22 mH	Through Hole	1	1	1
Murata Power Solutions Inc. 1007C	0.64 in	16.25 mm	General Purpose	310 VµS	70 °C	0.593 in 15.06 mm	0.593 in 15.06 mm	7.4 mH	Through Hole	1	1	1
Murata Power Solutions Inc. 1003C	0.64 in	16.25 mm		400 VµS	70 °C	0.593 in 15.06 mm	0.593 in 15.06 mm	12 mH	Through Hole	2 CT	1		8.22 g	0.29 oz	1
Murata Power Solutions Inc. 1002C	0.64 in	16.25 mm		200 VµS	70 °C	0.593 in 15.06 mm	0.593 in 15.06 mm	3 mH	Through Hole	1	1	1	8.22 g	0.29 oz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

TUBE ROHS COMPLIANT: YES
