V510SM10 - V150SM10

V510SM10

Active
Littelfuse/Commercial Vehicle Products

VARISTOR, MOV, 1.35KV, SMD ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheetDatasheet+1
V510SM10 - V150SM10

V510SM10

Active
Littelfuse/Commercial Vehicle Products

VARISTOR, MOV, 1.35KV, SMD ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsDatasheetDatasheet+1

Technical Specifications

Parameters and characteristics for this part

SpecificationV510SM10
Capacitance @ Frequency170 pF
Current - Surge5 kA
Energy86 J
Maximum AC Volts [Max]510 V
Maximum DC Volts670 V
Mounting TypeSurface Mount, MLCV
Number of Circuits1
Operating Temperature [Max]125 °C
Operating Temperature [Min]-40 °C
Package / Case2-SMD, J-Lead
Varistor Voltage (Max) [Max]902 V
Varistor Voltage (Min) [Min]738 V
Varistor Voltage (Typ)820 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyCut Tape (CT) 1$ 1.91
10$ 1.72
25$ 1.62
100$ 1.38
Digi-Reel® 1$ 1.91
10$ 1.72
25$ 1.62
100$ 1.38
Tape & Reel (TR) 300$ 1.30
600$ 1.13
1500$ 0.94
2100$ 0.89
NewarkEach (Supplied on Cut Tape) 1$ 1.87
10$ 1.68
25$ 1.59
50$ 1.47
100$ 1.35

Description

General part information

V510SM10 Series

820 V 5 kA Varistor 1 Circuit Surface Mount, MLCV 2-SMD, J-Lead
