38.51.0.024.0060
ActiveFinder Relays, Inc.
RELAY GEN PURPOSE SPDT 6A 24V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
38.51.0.024.0060
ActiveFinder Relays, Inc.
RELAY GEN PURPOSE SPDT 6A 24V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 38.51.0.024.0060 |
|---|---|
| Approval Agency | UKCA, cURus, RINA, CSA, CE, EAC |
| Coil Current | 12 mA |
| Coil Resistance | 2 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 24 VAC |
| Contact Form | SPDT (1 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 6 A |
| Features | Socket Included |
| Load - Max Switching [Max] | 2400 VA |
| Mounting Type | DIN Rail |
| Must Operate Voltage | 19.2 VAC |
| Must Release Voltage | 2.4 VAC/DC |
| Operate Time | 5 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 6 ms |
| Switching Voltage [Max] | 400 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 17.93 | |
| 10 | $ 15.94 | |||
| 25 | $ 15.14 | |||
| 50 | $ 14.34 | |||
| 100 | $ 13.55 | |||
| 250 | $ 12.35 | |||
| 500 | $ 11.55 | |||
Description
General part information
38.51.0 Series
General Purpose Relay SPDT (1 Form C) 24VAC/DC Coil DIN Rail
