LDT2400-170

Active

EOS Power India Private Ltd

AC/DC POWER SUPPLY SINGLE-OUT 170V 14A 2400W 22-PIN

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

AC/DC POWER SUPPLY SINGLE-OUT 170V 14A 2400W 22-PIN

Technical Specifications

Parameters and characteristics for this part

Specification	LDT2400-170

AC Voltage - Input [Max]	550 VAC
AC Voltage - Input [Min]	340 VAC
Applications	ITE (Commercial)
Current - Output (Max) [Max]	14 A
Efficiency	92 %
Features	Remote On/Off, PFC, Standby Output, IP20, Load Sharing, Remote Sense, Adjustable Output
Input Type	AC
Number of Outputs	1
Power (Watts)	2400 W
Size / Dimension [x]	101 mm
Size / Dimension [x]	3.98 in
Size / Dimension [y]	9.17 in
Size / Dimension [y]	233 mm
Size / Dimension [z]	160 mm
Size / Dimension [z]	6.3 in
Voltage - Isolation	4.2 kV
Voltage - Output 1	170 V

Part	Voltage - Output 1	Number of Outputs	Voltage - Isolation	Input Type	Efficiency	Applications	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Features	Current - Output (Max) [Max]	Power (Watts)	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]
EOS Power India Private Ltd LDT2400-170	170 V	1	4.2 kV	AC	92 %	ITE (Commercial)	340 VAC	550 VAC	Adjustable Output IP20 Load Sharing PFC Remote On/Off Remote Sense Standby Output	14 A	2400 W	160 mm	101 mm	9.17 in	3.98 in	6.3 in	233 mm
EOS Power India Private Ltd LDT2400-72	72 V	1	4.2 kV	AC	93 %	ITE (Commercial)	340 VAC	550 VAC	Adjustable Output IP20 Load Sharing PFC Remote On/Off Remote Sense Standby Output	33 A	2400 W	160 mm	101 mm	9.17 in	3.98 in	6.3 in	233 mm
EOS Power India Private Ltd LDT2400-24	24 V	1	4.2 kV	AC	92 %	ITE (Commercial)	340 VAC	550 VAC	Adjustable Output IP20 Load Sharing PFC Remote On/Off Remote Sense Standby Output	100 A	2400 W	160 mm	101 mm	9.17 in	3.98 in	6.3 in	233 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Arrow	N/A	1	$ 2509.16
Digikey	Box	4	$ 3022.43

General part information

AC/DC POWER SUPPLY SINGLE-OUT 170V 14A 2400W 22-PIN

Technical documentation and resources

No documents available
