LWR1606-6C1

Obsolete

EOS Power India Private Ltd

AC/DC DIN RAIL SUPPLY 125W

Search across all available documentation for this part.

Obsolete

EOS Power India Private Ltd

AC/DC DIN RAIL SUPPLY 125W

Technical Specifications

Parameters and characteristics for this part

Specification	LWR1606-6C1

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	Industrial, ITE (Commercial), Laboratory
DC Voltage - Input (Max) [Max]	350 V
DC Voltage - Input (Min) [Min]	90 V
Features	Adjustable Output, Universal Input
Input Type	AC or DC
Number of Outputs	1
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	125 W
Size / Dimension [x]	113.5 mm
Size / Dimension [x]	4.47 in
Size / Dimension [y]	4.25 in
Size / Dimension [y]	108 mm
Size / Dimension [z]	5.43 "
Size / Dimension [z]	137.9 mm
Standard Number	60950-1, UL 508, 61010-1

Part	Applications	DC Voltage - Input (Max) [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Number of Outputs	Power (Watts)	DC Voltage - Input (Min) [Min]	Features	Standard Number	Input Type	Operating Temperature [Max]	Operating Temperature [Min]	AC Voltage - Input [Min]	AC Voltage - Input [Max]
EOS Power India Private Ltd LWR1606-6C1	Industrial ITE (Commercial) Laboratory	350 V	113.5 mm	4.25 in	5.43 "	137.9 mm	4.47 in	108 mm	1	125 W	90 V	Adjustable Output Universal Input	60950-1 61010-1 UL 508	AC or DC	60 °C	-40 °C	85 VAC	264 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

AC/DC DIN RAIL SUPPLY 125W

Technical documentation and resources

No documents available
