RH2B-ULAC220-240V
ActiveIDEC
POWER RELAY, DPDT, 240 VAC, 10 A, RH SERIES, SOCKET, NON LATCHING
Deep-Dive with AI
Search across all available documentation for this part.
RH2B-ULAC220-240V
ActiveIDEC
POWER RELAY, DPDT, 240 VAC, 10 A, RH SERIES, SOCKET, NON LATCHING
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | RH2B-ULAC220-240V |
|---|---|
| Approval Agency | CSA, TUV, cURus, CE |
| Coil Current | 4.6 mA |
| Coil Resistance | 18.8 kOhms |
| Coil Type | Non Latching |
| Coil Voltage | 240 VAC |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Contact Rating (Current) | 10 A |
| Features | Lighted Indicator |
| Load - Max Switching | 300 W, 2400 VA |
| Mounting Type | Socketable |
| Must Operate Voltage | 192 VAC |
| Must Release Voltage | 72 VAC/DC |
| Operate Time | 20 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Relay Type | General Purpose |
| Release Time | 20 ms |
| Switching Voltage | 30 VDC, 240 VAC |
| Termination Style | Plug In, Quick Connect - 0.187" (4.7mm) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 19.20 | |
| 10 | $ 16.77 | |||
| 25 | $ 15.89 | |||
| 50 | $ 15.26 | |||
| 100 | $ 14.65 | |||
| 250 | $ 13.88 | |||
| 500 | $ 13.33 | |||
Description
General part information
RH2B-U Series
Isolated DC/DC Converters - Through Hole 1W DC/DC 4kV UNREG 5Vin +/-9Vout
