46.61.8.024.0054

Active

Finder Relays, Inc.

RELAY GEN PURPOSE SPDT 16A 24V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

46.61.8.024.0054

Active

Finder Relays, Inc.

RELAY GEN PURPOSE SPDT 16A 24V

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	46.61.8.024.0054

Approval Agency	cURus, VDE, CE, UKCA, CSA, CCC, RINA, ENEC, EAC
Coil Current	45 mA
Coil Resistance	533.3 Ohms
Coil Type	Non Latching
Coil Voltage	24 VAC
Contact Form	SPDT (1 Form C)
Contact Material	Silver Nickel (AgNi)
Contact Rating (Current)	16 A
Load - Max Switching	7040 VA
Mounting Type	Socketable
Must Operate Voltage	19.2 VAC
Must Release Voltage	4.8 VAC
Operate Time	15 ms
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-40 °C
Relay Type	General Purpose
Release Time	5 ms
Switching Voltage	440 VAC
Termination Style	Plug In, Quick Connect - 0.187" (4.7mm)

46.61.8 Series

Part	Relay Type	Coil Current	Termination Style	Mounting Type	Release Time	Coil Voltage	Contact Form	Contact Rating (Current)	Approval Agency	Switching Voltage	Operate Time	Must Operate Voltage	Contact Material	Load - Max Switching	Must Release Voltage	Coil Resistance	Coil Type	Operating Temperature [Min]	Operating Temperature [Max]
Finder Relays, Inc. 46.61.8.120.4054	General Purpose	8.4 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	120 VAC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	96 VAC	Silver Tin Oxide (AgSnO)	7040 VA	24 VAC	9 kOhms	Non Latching	-40 °C	70 °C
Finder Relays, Inc. 46.61.8.012.0054	General Purpose	90 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	12 VAC/DC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	9.6 VAC/DC	Silver Nickel (AgNi)	7040 VA	2.4 VAC/DC	80 Ohms	Non Latching	-40 °C	70 °C
Finder Relays, Inc. 46.61.8.120.5054	General Purpose	8.4 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	120 VAC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	96 VAC	Gold (Au) Silver Nickel (AgNi)	7040 VA	24 VAC	9 kOhms	Non Latching	-40 °C	70 °C
Finder Relays, Inc. 46.61.8.012.0040	General Purpose	90 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	12 VAC/DC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	9.6 VAC/DC	Silver Nickel (AgNi)	7040 VA	2.4 VAC/DC	80 Ohms	Non Latching	-40 °C	70 °C
Finder Relays, Inc. 46.61.8.240.0040	General Purpose	4.1 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	240 VAC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	192 VAC	Silver Nickel (AgNi)	7040 VA	48 VAC	31.5 kOhms	Non Latching	-40 °C	70 °C
Finder Relays, Inc. 46.61.8.230.0040	General Purpose	5 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	230 VAC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	184 VAC	Silver Nickel (AgNi)	7040 VA	46 VAC	28 kOhms	Non Latching	-40 °C	70 °C
Finder Relays, Inc. 46.61.8.240.0054	General Purpose	4.1 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	240 VAC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	192 VAC	Silver Nickel (AgNi)	7040 VA	48 VAC	31.5 kOhms	Non Latching	-40 °C	70 °C
Finder Relays, Inc. 46.61.8.024.0054	General Purpose	45 mA	Plug In Quick Connect - 0.187" (4.7mm)	Socketable	5 ms	24 VAC	SPDT (1 Form C)	16 A	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	440 VAC	15 ms	19.2 VAC	Silver Nickel (AgNi)	7040 VA	4.8 VAC	533.3 Ohms	Non Latching	-40 °C	70 °C

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 11.99
		10	$ 10.47
		25	$ 9.92
		50	$ 9.53
		100	$ 9.15
		250	$ 8.67
		500	$ 8.32
		1000	$ 7.99

Description

General part information

46.61.8 Series

General Purpose Relay SPDT (1 Form C) 24VAC Coil Socketable
