1-1904005-4
ActiveTE Connectivity Potter & Brumfield Relays
RELAY SPDT 12V
Deep-Dive with AI
Search across all available documentation for this part.
1-1904005-4
ActiveTE Connectivity Potter & Brumfield Relays
RELAY SPDT 12V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-1904005-4 |
|---|---|
| Coil Type | Non Latching |
| Coil Voltage | 12 VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Material | Silver (Ag) |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 8 VDC |
| Must Release Voltage | 0.5 VDC |
| Operate Time | 10 ms |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 10 ms |
| Termination Style | Plug In |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 6.91 | |
| 10 | $ 6.48 | |||
| 25 | $ 5.76 | |||
| 50 | $ 5.47 | |||
| 100 | $ 5.18 | |||
| 260 | $ 5.07 | |||
Description
General part information
1904005 Series
General Purpose Relay SPDT (1 Form C) 12VDC Coil Chassis Mount
