0194200004
ActiveMolex
CONN SOCKET 18-22AWG CRIMP GOLD
Deep-Dive with AI
Search across all available documentation for this part.
0194200004
ActiveMolex
CONN SOCKET 18-22AWG CRIMP GOLD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 0194200004 |
|---|---|
| Contact Finish | Gold |
| Contact Finish Thickness | 0.76 Ám |
| Contact Finish Thickness | 30 Áin |
| Contact Termination | Crimp |
| Pin or Socket | Socket |
| Wire Gauge [Max] | 22 AWG |
| Wire Gauge [Min] | 17.5 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.69 | |
| 10 | $ 0.58 | |||
| 25 | $ 0.55 | |||
| 50 | $ 0.52 | |||
| 100 | $ 0.49 | |||
| 250 | $ 0.46 | |||
| 500 | $ 0.44 | |||
| 1000 | $ 0.42 | |||
| Tape & Reel (TR) | 4000 | $ 0.38 | ||
| 8000 | $ 0.36 | |||
| 12000 | $ 0.35 | |||
| 20000 | $ 0.34 | |||
| 28000 | $ 0.33 | |||
Description
General part information
019420 Series
Socket Contact Gold 18-22 AWG Crimp
