24IBX15-50-0G
ActiveEOS Power India Private Ltd
DC DC CONVERTER 50-160V
Deep-Dive with AI
Search across all available documentation for this part.
24IBX15-50-0G
ActiveEOS Power India Private Ltd
DC DC CONVERTER 50-160V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 24IBX15-50-0G |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 1.6 A |
| Efficiency | 93 % |
| Features | UVLO, OTP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 17-DIP Module |
| Package / Case | 10 Leads |
| Size / Dimension [x] | 2.16 in |
| Size / Dimension [x] | 54.9 mm |
| Size / Dimension [y] | 54.7 mm |
| Size / Dimension [y] | 2.15 " |
| Size / Dimension [z] | 11.5 mm |
| Size / Dimension [z] | 0.45 " |
| Type | Non-Isolated PoL Module, Conformal Coated |
| Voltage - Input (Max) [Max] | 160 V |
| Voltage - Input (Min) [Min] | 15.4 V |
| Voltage - Output 1 [Max] | 160 V |
| Voltage - Output 1 [Min] | 50 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 172.20 | |
| 5 | $ 169.43 | |||
| 10 | $ 166.65 | |||
| 25 | $ 155.54 | |||
| 50 | $ 149.99 | |||
Description
General part information
24IBX15 Series
Non-Isolated PoL Module, Conformal Coated DC DC Converter 1 Output 50 ~ 160V 1.6A 15.4V - 160V Input
