SFM-1440-1
ActiveEast Electronics
BUZZER 5V 0.575" L X 0.575" W TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SFM-1440-1
ActiveEast Electronics
BUZZER 5V 0.575" L X 0.575" W TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SFM-1440-1 |
|---|---|
| Current - Supply | 2 mA |
| Frequency | 4 kHz |
| Height - Seated (Max) [Max] | 0.169 " |
| Height - Seated (Max) [Max] | 4.3 mm |
| Mounting Type | Through Hole |
| Operating Mode | Continuous |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -20 C |
| Size / Dimension [x] | 0.575 in |
| Size / Dimension [x] | 14.6 mm |
| Size / Dimension [y] | 14.6 mm |
| Size / Dimension [y] | 0.575 in |
| Sound Pressure Level (SPL) | 75 dB |
| Termination | PC Pins |
| Voltage - Rated | 5 V |
| Voltage Range [Max] | 20 V |
| Voltage Range [Min] | 1 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 2.08 | |
| 100 | $ 1.37 | |||
| 1000 | $ 1.12 | |||
Description
General part information
SFM-1440 Series
Buzzers 5 V 2mA 4kHz 75dB @ 5V, 10cm Through Hole PC Pins
