Q-7103S0005108I

Active

Amphenol Custom Cable

CBL ASSY RPSMA-SMB JACK-PLUG 9'

Deep-Dive with AI

Search across all available documentation for this part.

Q-7103S0005108I

Active

Amphenol Custom Cable

CBL ASSY RPSMA-SMB JACK-PLUG 9'

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-7103S0005108I

1st Connector	RP-SMA Jack
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	SMB Plug, Right Angle
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Female
Cable Impedance	50 Ohms
Cable Type	RG-316
Color	Copper
Connector Impedance	50 Ohms
Features	Shielded
Frequency - Max [Max]	3 GHz
Length	2.7 m
Length	9 ft
Length	108 in
Overall Impedance	50 Ohms
Style	RP-SMA to SMB

Q-7103S0 Series

Part	2nd Contact Gender	2nd Connector Mounting Type	2nd Connector	Overall Impedance	Frequency - Max [Max]	Cable Type	Style	1st Connector Mounting Type	1st Contact Gender	Features	Length [x]	Length [x]	Connector Impedance	Color	1st Connector	Cable Impedance	Length	Length	Length
Amphenol Custom Cable Q-7103S0005.25M	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded	9.843 "	250 mm	50 Ohms	Copper	RP-SMA Jack	50 Ohms
Amphenol Custom Cable Q-7103S0005002M	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms	6.6 ft	78.7 in	2 m
Amphenol Custom Cable Q-7103S00051.5M	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms	4.9 ft	59.1 in	1.5 m
Amphenol Custom Cable Q-7103S0005003M	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms	9.8 '	118.1 in	3 m
Amphenol Custom Cable Q-7103S0005006I	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms		6 in	152.4 mm
Amphenol Custom Cable Q-7103S0005012I	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms		12 "	304.8 mm
Amphenol Custom Cable Q-7103S0005036I	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms		36 in	91.44 cm
Amphenol Custom Cable Q-7103S0003108I	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	1 GHz	RG-174	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Black	RP-SMA Jack	50 Ohms	9 ft	108 in	2.7 m
Amphenol Custom Cable Q-7103S0005001M	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms	3.3 ft	39.4 in	1 m
Amphenol Custom Cable Q-7103S0005108I	Female	Free Hanging (In-Line)	SMB Plug Right Angle	50 Ohms	3 GHz	RG-316	RP-SMA to SMB	Free Hanging (In-Line)	Male	Shielded			50 Ohms	Copper	RP-SMA Jack	50 Ohms	9 ft	108 in	2.7 m

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 113.48
		25	$ 111.25
		50	$ 109.02
		100	$ 106.78
		250	$ 104.55

Description

General part information

Q-7103S0 Series

Cable Assembly Coaxial RP-SMA to SMB RG-316 108.0" (2.7m) 9.0'

Documents

Technical documentation and resources

No documents available
