10STRWHIGPT25

Active

Remington Industries

HOOK-UP STRND 10AWG 60V WHT 25'

Search across all available documentation for this part.

Active

Remington Industries

HOOK-UP STRND 10AWG 60V WHT 25'

Technical Specifications

Parameters and characteristics for this part

Specification	10STRWHIGPT25

Cable Type	Hook-Up
Conductor Material	Copper, Bare
Conductor Strand [custom]	19
Conductor Strand [custom]	23 AWG
Features	Chemical Resistant, Oil Resistant, Abrasion Resistant, Solvent Resistant
Jacket (Insulation) Diameter [diameter]	4.45 mm
Jacket (Insulation) Diameter [diameter]	0.175 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Length [x]	25 ft
Length [x]	7.62 m
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Voltage	60 V
Wire Gauge	10 AWG

Part	Length [x]	Length [x]	Jacket (Insulation) Material	Operating Temperature [Max]	Operating Temperature [Min]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Jacket Color	Voltage	Features	Wire Gauge	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]
Remington Industries 10STRBLAGPT25	25 ft	7.62 m	Poly-Vinyl Chloride (PVC)	85 °C	-40 °C	4.45 mm	0.175 in	Hook-Up	Black	60 V	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	10 AWG	Copper Bare	19	23 AWG
Remington Industries 10STRWHIGPT25	25 ft	7.62 m	Poly-Vinyl Chloride (PVC)	85 °C	-40 °C	4.45 mm	0.175 in	Hook-Up		60 V	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	10 AWG	Copper Bare	19	23 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 22.55

General part information

10 AWG Hook-Up Wire 19/23 White 60V 25.00' (7.62m)

Technical documentation and resources
