821-22-050-10-000101
ActiveMill-Max Manufacturing Corp.
CONN SPRING PISTON 50POS PCB
Deep-Dive with AI
Search across all available documentation for this part.
Documents821,823 Series (metric)
821-22-050-10-000101
ActiveMill-Max Manufacturing Corp.
CONN SPRING PISTON 50POS PCB
Deep-Dive with AI
Documents821,823 Series (metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | 821-22-050-10-000101 |
|---|---|
| Connector Type | Piston |
| Contact Finish | Gold |
| Contact Finish Thickness | 0.51 µm |
| Contact Finish Thickness | 20 µin |
| Material | Copper Alloy |
| Mounting Type | Through Hole |
| Number of Contacts | 50 |
| Number of Rows | 1 |
| Pitch [x] | 2.54 mm |
| Pitch [x] | 0.1 in |
821-22 Series
...
| Part | Number of Rows | Connector Type | Mounting Type | Pitch [x] | Pitch [x] | Material | Number of Contacts | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Number of Contacts [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 51 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 50 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 62 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 13 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 27 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 46 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 54 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 53 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | 14 | Gold | 0.51 µm | 20 µin | |
Mill-Max Manufacturing Corp. | 1 | Piston | Through Hole | 2.54 mm | 0.1 in | Copper Alloy | Gold | 0.51 µm | 20 µin | 19 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 34.16 | |
| 10 | $ 26.38 | |||
| 25 | $ 23.91 | |||
| 50 | $ 22.25 | |||
| 100 | $ 20.74 | |||
| 250 | $ 18.96 | |||
| 500 | $ 17.76 | |||
Description
General part information
821-22 Series
50 Position Spring Piston Connector Through Hole
