MSP-600-7.5

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 7.5V 600W

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 7.5V 600W

Technical Specifications

Parameters and characteristics for this part

Specification	MSP-600-7.5

Applications	Medical
Approval Agency	CB, cURus, CE
Efficiency	88 %
Features	PFC, Universal Input, Adjustable Output, Standby Output, Remote On/Off
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	1
Power (Watts)	600 W
Size / Dimension [x]	218 mm
Size / Dimension [x]	8.58 "
Size / Dimension [y]	4.13 in
Size / Dimension [y]	105 mm
Size / Dimension [z]	2.5 in
Size / Dimension [z]	63.5 mm
Type	Enclosed
Voltage - Input [Max]	370 VDC, 264 VAC
Voltage - Input [Min]	85 VAC, 120 VDC
Voltage - Isolation	4000 V
Voltage - Output 1	7.5 V

Part	Mounting Type	Efficiency	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Applications	Minimum Load Required	Approval Agency	Number of Outputs	Voltage - Input [Min]	Voltage - Input [Max]	Voltage - Output 1	Power (Watts)	Current - Output 1	Voltage - Isolation	Type	Features
MEAN WELL USA Inc. MSP-600-24	Chassis Mount	88 %	4.13 in	218 mm	8.58 "	2.5 in	63.5 mm	105 mm	Medical		CB CE cURus	1	85 VAC 120 VDC	264 VAC 370 VDC	24 V	648 W	27 A	4000 V	Enclosed	Adjustable Output PFC Remote On/Off Standby Output Universal Input
MEAN WELL USA Inc. MSP-600-7.5	Chassis Mount	88 %	4.13 in	218 mm	8.58 "	2.5 in	63.5 mm	105 mm	Medical		CB CE cURus	1	85 VAC 120 VDC	264 VAC 370 VDC	7.5 V	600 W		4000 V	Enclosed	Adjustable Output PFC Remote On/Off Standby Output Universal Input

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	8	$ 197.00

General part information

Enclosed AC DC Converters 1 Output 7.5V 85 ~ 264 VAC, 120 ~ 370 VDC Input
