PEM1-S12-S3-S

Obsolete

CUI Inc.

DC DC CONVERTER 3.3V 1W

Search across all available documentation for this part.

Obsolete

CUI Inc.

DC DC CONVERTER 3.3V 1W

Technical Specifications

Parameters and characteristics for this part

Part	Applications	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Approval Agency	Features	Voltage - Input (Max) [Max]	Standard Number	Voltage - Output 2	Mounting Type	Voltage - Isolation	Voltage - Input (Min) [Min]	Type	Current - Output (Max)	Current - Output (Max)	Efficiency	Voltage - Output 1	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Number of Outputs	Current - Output (Max) [Max]	Standard Number
CUI Inc. PEM1-S12-D5-S	ITE (Commercial)	0.77 in	19.5 mm	0.24 "	9.3 mm	6 mm	0.37 in	EN UL	SCP	13.2 V	55024 55032 Class A 60950-1	-5 V	Through Hole	3000 V	10.8 V	Isolated Module	100 mA	100 mA	80 %	5 V	7-SIP Module 5 Leads	-40 °C	105 ░C	2
CUI Inc. PEM1-S12-S15-S	ITE (Commercial)	0.77 in	19.5 mm	0.24 "	9.3 mm	6 mm	0.37 in	CB Scheme EN IEC UL	SCP	13.2 V			Through Hole	3000 V	10.8 V	Isolated Module			81 %	15 V	7-SIP Module 4 Leads	-40 °C	105 ░C	1	67 mA	55024 55032 60950.1 61000.32 61000.33
CUI Inc. PEM1-S12-S3-S	ITE (Commercial)	0.77 in	19.5 mm	0.24 "	9.3 mm	6 mm	0.37 in		SCP	13.2 V			Through Hole	3000 V	10.8 V	Isolated Module			75 %	3.3 V	7-SIP Module 4 Leads	-40 °C	105 ░C	1	303 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 3.3V 303mA 10.8V - 13.2V Input

Technical documentation and resources

No documents available
