SMBJ24CA
ActiveSemtech Corporation
DIODE TVS SINGLE BI-DIR 24V 600W 2-PIN DO-214AA T/R
Deep-Dive with AI
Search across all available documentation for this part.
SMBJ24CA
ActiveSemtech Corporation
DIODE TVS SINGLE BI-DIR 24V 600W 2-PIN DO-214AA T/R
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SMBJ24CA |
|---|---|
| Applications | Telecom |
| Bidirectional Channels [custom] | 1 |
| Current - Peak Pulse (10/1000µs) | 15.4 A |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 175 ░C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | SMB, DO-214AA |
| Power - Peak Pulse | 600 W |
| Power Line Protection | False |
| Supplier Device Package | SMB |
| Supplier Device Package | DO-214AA |
| Type | Zener |
| Voltage - Breakdown (Min) [Min] | 26.7 V |
| Voltage - Clamping (Max) @ Ipp [Max] | 38.9 V |
| Voltage - Reverse Standoff (Typ) | 24 V |
