1SS361UDJ-7

Active

Diodes Inc

DIODE ARRAY GP 80V 250MA SOT963

Search across all available documentation for this part.

Active

Diodes Inc

DIODE ARRAY GP 80V 250MA SOT963

Technical Specifications

Parameters and characteristics for this part

Specification	1SS361UDJ-7

Current - Average Rectified (Io) (per Diode)	250 mA
Current - Reverse Leakage @ Vr	1 µA
Diode Configuration	2 Independent
Mounting Type	Surface Mount
Operating Temperature - Junction [Max]	150 °C
Operating Temperature - Junction [Min]	-65 C
Package / Case	SOT-963
Reverse Recovery Time (trr)	4 ns
Speed	200 mA, 500 ns
Supplier Device Package	SOT-963
Technology	Standard
Voltage - DC Reverse (Vr) (Max) [Max]	80 V
Voltage - Forward (Vf) (Max) @ If	1.23 V

Switching Diode

Part	Mounting Type	Diode Configuration	Supplier Device Package	Technology	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max) [Max]	Package / Case	Voltage - Forward (Vf) (Max) @ If	Current - Average Rectified (Io) (per Diode)	Speed	Capacitance @ Vr, F	Speed	Current - Average Rectified (Io)
Diodes Inc 1SS361UDJ-7	Surface Mount	2 Independent	SOT-963	Standard	150 °C	-65 C	4 ns	1 µA	80 V	SOT-963	1.23 V	250 mA	200 mA 500 ns
Diodes Inc 1SS361LPH4-7B	Surface Mount		X2-DFN1006-2	Standard	150 °C	-55 °C	4 ns	500 nA	80 V	0402 (1006 Metric)			200 mA	3 pF	Any Speed	100 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Switching Diode
