1.8HDL
ActiveBivar Inc.
LED, THROUGH HOLE, 1.8MM, HE RED, 625NM, 2MCD, DIFFUSED LENS, 50 DEG VIEWING ANGLE, LOW CURRENT / BAG
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1.8HDL
ActiveBivar Inc.
LED, THROUGH HOLE, 1.8MM, HE RED, 625NM, 2MCD, DIFFUSED LENS, 50 DEG VIEWING ANGLE, LOW CURRENT / BAG
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1.8HDL |
|---|---|
| Color | Red |
| Configuration | Standard |
| Current - Test | 2 mA |
| Height (Max) [Max] [z] | 3 mm |
| Lens Color | Red |
| Lens Size [diameter] | 1.8 mm |
| Lens Style | Round with Domed Top |
| Lens Transparency | Diffused |
| Millicandela Rating | 2 mcd |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Supplier Device Package | 1.8mm Discrete LED |
| Viewing Angle | 50 ° |
| Voltage - Forward (Vf) (Typ) | 2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
1.8HD Series
Red LED Indication - Discrete 2V Radial
