60B683C

Active

Murata Power Solutions Inc.

FIXED IND 68UH 9A 17 MOHM SMD

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

FIXED IND 68UH 9A 17 MOHM SMD

Technical Specifications

Parameters and characteristics for this part

Part	Shielding	Frequency - Self Resonant	Current Rating (Amps)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Inductance	Tolerance	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Type	DC Resistance (DCR)	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Inductance Frequency - Test	Mounting Type	DC Resistance (DCR) [Max]
Murata Power Solutions Inc. 60B224C	Unshielded	3.21 MHz	5 A	20 mm	0.787 "	220 µH	15 %	1.063 in	19.5 mm	0.768 in	27 mm	Wirewound	50 mOhm	Nonstandard	85 °C	-40 °C	100 kHz	Surface Mount
Murata Power Solutions Inc. 60B334C	Unshielded	2.66 MHz	4 A	20 mm	0.787 "	330 µH	15 %	1.063 in	19.5 mm	0.768 in	27 mm	Wirewound		Nonstandard	85 °C	-40 °C	100 kHz	Surface Mount	80 mOhm
Murata Power Solutions Inc. 60B473C	Unshielded	7.45 MHz	10.5 A	20 mm	0.787 "	47 µH	15 %	1.063 in	19.5 mm	0.768 in	27 mm	Wirewound	13 mOhm	Nonstandard	85 °C	-40 °C	100 kHz	Surface Mount
Murata Power Solutions Inc. 60B683C	Unshielded	6.07 MHz		20 mm	0.787 "	68 µH	15 %	1.063 in	19.5 mm	0.768 in	27 mm	Wirewound	17 mOhm	Nonstandard	85 °C	-40 °C	100 kHz	Surface Mount
Murata Power Solutions Inc. 60B104C	Unshielded	4.98 MHz	7.5 A	20 mm	0.787 "	100 µH	15 %	1.063 in	19.5 mm	0.768 in	27 mm	Wirewound	25 mOhm	Nonstandard	85 °C	-40 °C	100 kHz	Surface Mount
Murata Power Solutions Inc. 60B474C	Unshielded	2.15 MHz	3.5 A	20 mm	0.787 "		15 %	1.063 in	19.5 mm	0.768 in	27 mm	Wirewound	100 mOhm	Nonstandard	85 °C	-40 °C	100 kHz	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 2.20

General part information

68 µH Unshielded Wirewound Inductor 9 A 17mOhm Max Nonstandard
