09200042611

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, 4+PE SIGNAL, HAN A SERIES, INSERT, 5 CONTACTS, 4A, PLUG, SCREW PIN

Search across all available documentation for this part.

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, 4+PE SIGNAL, HAN A SERIES, INSERT, 5 CONTACTS, 4A, PLUG, SCREW PIN

Technical Specifications

Parameters and characteristics for this part

Specification	09200042611

Color	Gray
Contact Finish	Silver
Contact Material	Copper Alloy
Current Rating (Amps)	10 A
Gender	Male
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Number of Positions	4+Ground
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Size	3 A
Termination Style	Screw
Voltage Rating	600 V

Part	Number of Positions	Voltage Rating	Size	Housing Material	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Gender	Contact Material	Termination Style	Contact Finish	Color	Material Flammability Rating
HARTING Technology Group 09200042611	4+Ground	600 V	3 A	Polycarbonate (PC)	10 A	125 °C	-40 °C	Male	Copper Alloy	Screw	Silver	Gray	UL94 V-0

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

The 0920 004 2611 from Harting is a Han A series 4 position light grey (RAL 7032) colour male insert screw terminal with 3A size.
