SC3102DULTRT
NRNDSemtech Corporation
IC REG BUCK 1.1V 2A 16MLPQ
Deep-Dive with AI
Search across all available documentation for this part.
SC3102DULTRT
NRNDSemtech Corporation
IC REG BUCK 1.1V 2A 16MLPQ
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SC3102DULTRT |
|---|---|
| Current - Output | 2 A |
| Frequency - Switching | 1.5 MHz |
| Function | Step-Down |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Positive |
| Output Type | 1.81 mOhm |
| Package / Case | 16-UFQFN Exposed Pad |
| Supplier Device Package | 16-MLPQ-UT (3x3) |
| Synchronous Rectifier | True |
| Topology | Buck |
| Voltage - Input (Max) [Max] | 5.5 V |
| Voltage - Input (Min) [Min] | 2.9 V |
| Voltage - Output (Min/Fixed) | 1.1 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 3000 | $ 0.98 | |
| 6000 | $ 0.95 | |||
Description
General part information
SC3102 Series
Buck Switching Regulator IC Positive Fixed 1.1V 1 Output 2A 16-UFQFN Exposed Pad
Documents
Technical documentation and resources
No documents available
