HEC208N00000200000

Active

TE Intercontec

CONN RCPT HSG MALE 10POS PNL MT

Search across all available documentation for this part.

Active

TE Intercontec

CONN RCPT HSG MALE 10POS PNL MT

Technical Specifications

Parameters and characteristics for this part

Specification	HEC208N00000200000

Connector Type	Receptacle Housing
Contact Shape	Circular
Fastening Type	Push-Twist
Housing Color	Silver
Includes	1 Connector, 1 O-Ring
Ingress Protection	IP66/IP67
Insert Material	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 V-0
Mounting Feature	Flange
Note	Contacts Not Included
Number of Positions	10
Operating Temperature [Max]	130 °C
Operating Temperature [Min]	-20 C
Orientation	Keyed
Shell Finish	Chromate
Shell Material	Zinc Die Cast
Shell Size - Insert	M23-10
Shielding	Unshielded
Type	For Male Pins

Part	Includes	Connector Type	Shell Material	Type	Shell Finish	Shielding	Contact Shape	Number of Positions	Note	Shell Size - Insert	Ingress Protection	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Orientation	Mounting Feature	Material Flammability Rating	Housing Color	Insert Material
TE Intercontec HEC208N00000200000	1 Connector 1 O-Ring	Receptacle Housing	Zinc Die Cast	For Male Pins	Chromate	Unshielded	Circular	10	Contacts Not Included	M23-10	IP66/IP67	-20 C	130 °C	Push-Twist	Keyed	Flange	UL94 V-0	Silver	Polyamide (PA66) Nylon 6/6

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 (3 + 6 Power + PE) Position Circular Connector Receptacle Housing Panel Mount
