SRR4018-680Y
ActiveBourns Inc.
POWER INDUCTOR (SMD), 68 ΜH, 500 MA, SHIELDED, 380 MA, SRR4018 SERIES
Deep-Dive with AI
Search across all available documentation for this part.
SRR4018-680Y
ActiveBourns Inc.
POWER INDUCTOR (SMD), 68 ΜH, 500 MA, SHIELDED, 380 MA, SRR4018 SERIES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SRR4018-680Y |
|---|---|
| Current - Saturation (Isat) | 380 mA |
| Current Rating (Amps) | 0.5 A |
| DC Resistance (DCR) | 860 mOhm |
| Frequency - Self Resonant | 13 MHz |
| Height - Seated (Max) [Max] [z] | 2 mm |
| Height - Seated (Max) [Max] [z] | 0.079 in |
| Inductance | 68 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4848 Metric |
| Package / Case | 1919 |
| Q @ Freq | 2.52 MHz, 7 |
| Shielding | Shielded |
| Size / Dimension [x] | 0.189 " |
| Size / Dimension [x] | 4.8 mm |
| Size / Dimension [y] | 4.8 mm |
| Size / Dimension [y] | 0.189 in |
| Tolerance | 30 % |
| Type | Wirewound, Drum Core |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.79 | |
| 10 | $ 0.68 | |||
| 25 | $ 0.62 | |||
| 50 | $ 0.57 | |||
| 100 | $ 0.50 | |||
| 250 | $ 0.47 | |||
| Digi-Reel® | 1 | $ 0.79 | ||
| 10 | $ 0.68 | |||
| 25 | $ 0.62 | |||
| 50 | $ 0.57 | |||
| 100 | $ 0.50 | |||
| 250 | $ 0.47 | |||
| Tape & Reel (TR) | 800 | $ 0.38 | ||
| 1600 | $ 0.36 | |||
| 2400 | $ 0.35 | |||
| 5600 | $ 0.34 | |||
| 20000 | $ 0.33 | |||
| Newark | Each (Supplied on Full Reel) | 1 | $ 0.39 | |
| 5000 | $ 0.39 | |||
| 10000 | $ 0.36 | |||
| 20000 | $ 0.33 | |||
| 30000 | $ 0.31 | |||
| 50000 | $ 0.30 | |||
Description
General part information
SRR4018 Series
68 µH Shielded Drum Core, Wirewound Inductor 500 mA 860mOhm Max 1919 (4848 Metric)
