Q8F1BXXB12E

Active

APEM

INDICATOR 12V 8MM FLUSH BLUE

Search across all available documentation for this part.

Active

APEM

INDICATOR 12V 8MM FLUSH BLUE

Technical Specifications

Parameters and characteristics for this part

Specification	Q8F1BXXB12E

Ingress Protection	IP67
Lamp Color	Blue
Lens Color	Blue
Lens Size	T-1 3/4
Lens Size	5 mm
Lens Transparency	Diffused
Millicandela Rating	200 mcd
Panel Cutout Dimensions [custom]	0.31 in
Panel Cutout Dimensions [custom]	7.87 mm
Panel Cutout Shape	Round
Ratings	DC
Termination Style	Solder Lug
Type	LED
Viewing Angle	100 °
Voltage	12 V

Part	Lens Size	Lens Size	Panel Cutout Dimensions [custom]	Panel Cutout Dimensions [custom]	Type	Panel Cutout Shape	Lens Color	Ingress Protection	Viewing Angle	Lamp Color	Voltage	Millicandela Rating	Ratings	Termination Style	Lens Transparency
APEM Q8F1BXXB12E	T-1 3/4	5 mm	0.31 in	7.87 mm	LED	Round	Blue	IP67	100 °	Blue	12 V	200 mcd	DC	Solder Lug	Diffused

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator Blue Diffused 100° 12V 20mA Solder Lug
