FI4D096RK

Active

Belden Inc.

CBL FIBER OPTIC 125UM MULTIMODE

Search across all available documentation for this part.

Active

Belden Inc.

CBL FIBER OPTIC 125UM MULTIMODE

Technical Specifications

Parameters and characteristics for this part

Specification	FI4D096RK

Cladding Diameter [diameter]	125 µm
Core Diameter [diameter]	50 µm
Features	Rip Cord
Features	96 Fibers
Jacket (Insulation) Diameter [diameter]	24.21 mm
Jacket (Insulation) Diameter [diameter]	0.953 "
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Violet
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Ratings	OFNR
Style	Multiple Fibers
Tensile Strength	40.8 kg
Type	Multimode

Part	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Material	Ratings	Features	Features	Cladding Diameter [diameter]	Type	Core Diameter [diameter]	Tensile Strength	Style	Jacket Color	Operating Temperature [Min]	Operating Temperature [Max]
Belden Inc. FI4D096AK
Belden Inc. FI4D096FKA
Belden Inc. FI4D096FK
Belden Inc. FI4D096PKA
Belden Inc. FI4D096AKA
Belden Inc. FI4D096RK	24.21 mm	0.953 "	Poly-Vinyl Chloride (PVC)	OFNR	Rip Cord	96 Fibers	125 µm	Multimode	50 µm	40.8 kg	Multiple Fibers	Violet	-20 C	70 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1640	$ 29.93

General part information

Fiber Optic Cable Violet Multimode 125µm
