CA3292AM96

Active

Harris Corporation

QUAD-GATED INVERTING POWER DRIVE

Search across all available documentation for this part.

Active

Harris Corporation

QUAD-GATED INVERTING POWER DRIVE

Technical Specifications

Parameters and characteristics for this part

Specification	CA3292AM96

Current - Output (Max) [Max]	600 mA
Fault Protection	Over Temperature, Current Limiting (Fixed), Over Voltage
Features	Load Discharge, Status Flag
Input Type	Non-Inverting
Interface	On/Off
Mounting Type	Surface Mount
Number of Outputs	4
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Output Configuration	Low Side
Output Type	Bipolar
Package / Case	28-SOIC
Package / Case [x]	0.295 in
Package / Case [y]	7.5 mm
Ratio - Input:Output [custom]	1:1
Supplier Device Package	28-SOIC
Switch Type	Relay, Solenoid Driver
Voltage - Load	15 V
Voltage - Supply (Vcc/Vdd)	7 V

Part	Features	Voltage - Load	Output Type	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Ratio - Input:Output [custom]	Switch Type	Supplier Device Package	Output Configuration	Package / Case	Package / Case [x]	Package / Case [y]	Interface	Current - Output (Max) [Max]	Input Type	Fault Protection	Voltage - Supply (Vcc/Vdd)	Number of Outputs
Harris Corporation CA3292AM96	Load Discharge Status Flag	15 V	Bipolar	Surface Mount	-40 °C	125 °C	1:1	Relay Solenoid Driver	28-SOIC	Low Side	28-SOIC	0.295 in	7.5 mm	On/Off	600 mA	Non-Inverting	Current Limiting (Fixed) Over Temperature Over Voltage	7 V	4

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	156	$ 1.93

General part information

Power Switch/Driver 1:1 Bipolar 600mA 28-SOIC

Technical documentation and resources

No documents available
