LM3502SQ-16

Active

National Semiconductor

IC LED DRV RGLTR PWM 16WQFN

Search across all available documentation for this part.

Active

National Semiconductor

IC LED DRV RGLTR PWM 16WQFN

Technical Specifications

Parameters and characteristics for this part

Part	Dimming	Voltage - Supply (Max)	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Type	Topology	Number of Outputs	Supplier Device Package	Frequency	Current - Output / Channel	Mounting Type	Voltage - Supply (Min) [Min]	Applications	Voltage - Output
National Semiconductor LM3502ITL-25/NOPB	PWM	5.5 V	10-WFBGA DSBGA	85 °C	-40 °C	DC DC Regulator	Step-Up (Boost)	2	10-DSBGA	1 MHz	600 mA	Surface Mount	2.5 V	Backlight	25 V
National Semiconductor LM3502SQ-35	PWM	5.5 V	16-WFQFN Exposed Pad	85 °C	-40 °C	DC DC Regulator	Step-Up (Boost)	2	16-WQFN (4x4)	1 MHz	750 mA	Surface Mount	2.5 V	Backlight	35 V
National Semiconductor LM3502SQ-16	PWM	5.5 V	16-WFQFN Exposed Pad	85 °C	-40 °C	DC DC Regulator	Step-Up (Boost)	2	16-WQFN (4x4)	1 MHz	400 mA	Surface Mount	2.5 V	Backlight	16 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	166	$ 1.81

General part information

LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) PWM Dimming 400mA (Switch) 16-WQFN (4x4)
