GS 63B/6
ActiveLeuze
FORKED PHOTOELECTRIC SENSOR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
GS 63B/6
ActiveLeuze
FORKED PHOTOELECTRIC SENSOR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | GS 63B/6 |
|---|---|
| Cable Length | 78.74 in |
| Cable Length | 2 m |
| Connection Method | Cable |
| Ingress Protection | IEC 60947-5-2 IP67 |
| Light Source | 940 nm |
| Light Source | Infrared |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -20 C |
| Output Configuration | NPN/PNP, Push-Pull |
| Response Time | 500 µs |
| Sensing Distance | 3 mm |
| Sensing Distance | 0.118 in |
| Voltage - Supply [Max] | 30 VDC |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 292.00 | |
Description
General part information
GS 63 Series
Optical Sensor 0.118" (3mm) Push-Pull, NPN/PNP
