PAT-30-DD-B-20-S-9

Active

FiberSource, Inc

SCA-SCA SM 2MM YELLOW SIMPLX 30M

Search across all available documentation for this part.

Active

FiberSource, Inc

SCA-SCA SM 2MM YELLOW SIMPLX 30M

Technical Specifications

Parameters and characteristics for this part

Part	2nd Connector	Color - Cable	Type	Color - Connectors	1st Connector	Operating Temperature [Max]	Operating Temperature [Min]	Return Loss	Insertion Loss	Cable Diameter [diameter]	Cable Diameter [diameter]	Length - Overall [x]	Length - Overall	Fiber Type
FiberSource, Inc PAT-30-JH-B-20-D-9	LC Duplex	Yellow	Duplex Singlemode	Blue	LC Duplex	85 °C	-40 °C	65 dB	0.3 dB	2 mm	0.08 in	98.4 ft	30 m
FiberSource, Inc PAT-30-JD-B-20-S-9	SC/APC	Yellow	Simplex Singlemode		LC/APC	85 °C	-40 °C	55 dB 65 dB	0.2 dB	2 mm	0.08 in	98.4 ft	30 m
FiberSource, Inc PAT-30-DD-B-20-D-9	SC/APC	Yellow	Duplex Singlemode	Blue	SC/APC	85 °C	-40 °C	65 dB	0.3 dB	2 mm	0.08 in	98.4 ft	30 m
FiberSource, Inc PAT-30-DC-B-20-S-9	SC/UPC	Yellow	Simplex Singlemode		SC/APC	85 °C	-40 °C	55 dB 65 dB	0.2 dB	2 mm	0.08 in	98.4 ft	30 m
FiberSource, Inc PAT-30-NL-F-20-D-A	SC Duplex		Duplex Multimode OM3	Blue	LC Duplex	85 °C	-40 °C			2 mm	0.08 in	98.4 ft	30 m	50/125
FiberSource, Inc PAT-30-NN-F-20-D-A	LC Duplex		Duplex Multimode OM3	Blue	LC Duplex	85 °C	-40 °C			2 mm	0.08 in	98.4 ft	30 m	50/125
FiberSource, Inc PAT-30-HH-B-20-D-9	LC Duplex	Yellow	Duplex Singlemode	Blue	LC Duplex	85 °C	-40 °C	55 dB	0.3 dB	2 mm	0.08 in	98.4 ft	30 m
FiberSource, Inc PAT-30-DD-B-20-S-9	SC/APC	Yellow	Simplex Singlemode		SC/APC	85 °C	-40 °C	55 dB 65 dB	0.2 dB	2 mm	0.08 in	98.4 ft	30 m
FiberSource, Inc PAT-30-HD-B-20-D-9	SC Duplex	Yellow	Duplex Singlemode	Blue	LC Duplex	85 °C	-40 °C	65 dB	0.3 dB	2 mm	0.08 in	98.4 ft	30 m
FiberSource, Inc PAT-30-CC-B-20-D-9	SC/UPC	Yellow	Duplex Singlemode	Blue	SC/UPC	85 °C	-40 °C	55 dB	0.3 dB	2 mm	0.08 in	98.4 ft	30 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Fiber Optic SC/APC To SC/APC 98.4' (30.0m)
