C8RRG-1436M
ActiveCW Industries
DIP CABLE - CDR14G/AE14M/CDR14G
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | C8RRG-1436M |
|---|---|
| Cable Termination | IDC |
| Color | Ribbon, Multiple |
| Connector Type | DIP to DIP, Reversed |
| Contact Finish | Gold |
| Contact Finish Thickness | 10 Áin |
| Contact Finish Thickness | 0.25 Ám |
| Features | Strain Relief |
| Length [x] | 3 ft |
| Length [x] | 914.4 mm |
| Number of Positions | 14 |
| Number of Rows | 2 |
| Pitch - Cable | 0.05 " |
| Pitch - Cable | 1.27 mm |
| Pitch - Connector | 0.1 in |
| Pitch - Connector | 2.54 mm |
| Shielding | Unshielded |
| Usage | Socket (0.3"), Board In |
C8RRG-1 Series
| Part | Pitch - Connector | Pitch - Connector | Pitch - Cable | Pitch - Cable | Features | Contact Finish | Shielding | Number of Rows | Cable Termination | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Length [x] | Length [x] | Number of Positions | Usage | Color | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CW Industries | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | Strain Relief | Gold | Unshielded | 2 | IDC | DIP to DIP Reversed | 10 Áin | 0.25 Ám | 457.2 mm | 1.5 ft | 16 | Board In Socket (0.3") | ||
CW Industries | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | Strain Relief | Gold | Unshielded | 2 | IDC | DIP to DIP Reversed | 10 Áin | 0.25 Ám | 914.4 mm | 3 ft | 16 | Board In Socket (0.3") | ||
CW Industries | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | Strain Relief | Gold | Unshielded | 2 | IDC | DIP to DIP Reversed | 10 Áin | 0.25 Ám | 457.2 mm | 1.5 ft | 16 | Board In Socket (0.3") | Multiple Ribbon | |
CW Industries | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | Strain Relief | Gold | Unshielded | 2 | IDC | DIP to DIP Reversed | 10 Áin | 0.25 Ám | 457.2 mm | 1.5 ft | Board In Socket (0.3") | 14 | ||
CW Industries | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | Strain Relief | Gold | Unshielded | 2 | IDC | DIP to DIP Reversed | 10 Áin | 0.25 Ám | 914.4 mm | 3 ft | 16 | Board In Socket (0.3") | Multiple Ribbon | |
CW Industries | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | Strain Relief | Gold | Unshielded | 2 | IDC | DIP to DIP Reversed | 10 Áin | 0.25 Ám | 914.4 mm | 3 ft | Board In Socket (0.3") | Multiple Ribbon | 14 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 11.75 | |
| 10 | $ 9.02 | |||
| 25 | $ 8.15 | |||
| 50 | $ 7.56 | |||
| 100 | $ 7.03 | |||
| 250 | $ 6.40 | |||
| 500 | $ 5.97 | |||
| 1000 | $ 5.59 | |||
Description
General part information
C8RRG-1 Series
14 Position Cable Assembly Rectangular DIP to DIP, Reversed 3.00' (914.40mm)
