RJFTV22N00

Active

Amphenol Socapex

CONN MOD JACK 8P8C UNSHIELDED

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

RJFTV22N00

Active

Amphenol Socapex

CONN MOD JACK 8P8C UNSHIELDED

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	RJFTV22N00

Connector Type	Jack
Features	Circular Threaded Coupling
Ingress Protection	IP67 - Dust Tight, Waterproof
LED Color	Does Not Contain LED
Mounting Type	Panel Mount, Square Flange
Number of Ports	1
Number of Positions/Contacts	8p8c (RJ45, Ethernet)
Number of Rows	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Orientation	Straight
Ratings	Cat5e
Shielding	Unshielded
Tab Direction	User Selectable
Termination	PC Board, Solder

RJFTV22 Series

Part	Shielding	Mounting Type	Length [x]	Length [x]	Number of Positions/Contacts	Color	Style	Features	Cable Type	Connector Type	Length	Length	Number of Ports	Ingress Protection	Operating Temperature [Max]	Operating Temperature [Min]	Termination	Number of Rows	Ratings	Tab Direction	Orientation	LED Color
Amphenol Socapex RJFTV22G05100BTX	Double Shielded	Flange Panel Mount	1.64 ft	500 mm	8p8c (RJ45 Ethernet)	Gray	Cat5e Industrial Environments - IP68	Circular Threaded Coupling	Round Cable	Jack to Plug
Amphenol Socapex RJFTV22N10100BTX	Double Shielded	Flange Panel Mount	3.28 ft	1 m	8p8c (RJ45 Ethernet)	Gray	Cat5e Industrial Environments - IP68	Circular Threaded Coupling	Round Cable	Jack to Plug
Amphenol Socapex RJFTV22G15100BTX	Double Shielded	Flange Panel Mount			8p8c (RJ45 Ethernet)	Gray	Cat5e Industrial Environments - IP68	Circular Threaded Coupling	Round Cable	Jack to Plug	4.92 '	1.5 m
Amphenol Socapex RJFTV22G00	Unshielded	Panel Mount Square Flange			8p8c (RJ45 Ethernet)			Circular Threaded Coupling		Jack			1	IP67 - Dust Tight Waterproof	85 °C	-40 °C	PC Board Solder	1	Cat5e	User Selectable	Straight	Does Not Contain LED
Amphenol Socapex RJFTV22G03100BTX	Double Shielded	Flange Panel Mount	0.98 ft	300 mm	8p8c (RJ45 Ethernet)	Gray	Cat5e Industrial Environments - IP68	Circular Threaded Coupling	Round Cable	Jack to Plug
Amphenol Socapex RJFTV22N06100BTX	Double Shielded	Flange Panel Mount			8p8c (RJ45 Ethernet)	Gray	Cat5e Industrial Environments - IP68	Circular Threaded Coupling	Round Cable	Jack to Plug	1.97 ft	600 mm
Amphenol Socapex RJFTV22N00	Unshielded	Panel Mount Square Flange			8p8c (RJ45 Ethernet)			Circular Threaded Coupling		Jack			1	IP67 - Dust Tight Waterproof	85 °C	-40 °C	PC Board Solder	1	Cat5e	User Selectable	Straight	Does Not Contain LED
Amphenol Socapex RJFTV22N05100BTX	Double Shielded	Flange Panel Mount	1.64 ft	500 mm	8p8c (RJ45 Ethernet)	Gray	Cat5e Industrial Environments - IP68	Circular Threaded Coupling	Round Cable	Jack to Plug

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 60.49
		10	$ 55.51
		25	$ 53.37
		50	$ 51.59
		100	$ 48.75

Description

General part information

RJFTV22 Series

Jack Modular Connector 8p8c (RJ45, Ethernet) Straight Unshielded Cat5e

Documents

Technical documentation and resources
