1.01.102.001/0104

Active

RAFI USA

SWITCH, PUSHBUTTON, MOM, OPAQUE, BLACK

Search across all available documentation for this part.

Active

RAFI USA

SWITCH, PUSHBUTTON, MOM, OPAQUE, BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	1.01.102.001/0104

Actuator Marking	No Marking
Actuator Type	Round, Button
Circuit	DPST-NO
Color - Actuator/Cap	Black
Current Rating (Amps)	2 A
Electrical Life	50000 Cycles
Ingress Protection	IP40
Mounting Type	Panel Mount, Front
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Panel Cutout Dimensions [diameter]	18.2 mm
Switch Function	Off-Mom
Termination Style	Screw Terminal
Type	Standard
Voltage Rating - AC	250 V

Part	Color - Actuator/Cap	Voltage Rating - AC	Operating Temperature [Min]	Operating Temperature [Max]	Actuator Type	Actuator Marking	Mounting Type	Switch Function	Panel Cutout Dimensions [diameter]	Ingress Protection	Circuit	Current Rating (Amps)	Electrical Life	Type	Termination Style
RAFI USA 1.01.102.001/0104	Black	250 V	-25 °C	85 °C	Button Round	No Marking	Panel Mount Front	Off-Mom	18.2 mm	IP40	DPST-NO	2 A	50000 Cycles	Standard	Screw Terminal
RAFI USA 1.01102.1210104
RAFI USA 1.01.102.001/0205

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pushbutton Switch DPST-NO Standard Panel Mount, Front
