DM1B-DSF-PEJ(22)
ObsoleteHirose Electric USA, Inc.
CONN SD CARD PUSH-PUSH R/A SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | DM1B-DSF-PEJ(22) |
|---|---|
| Card Type | Secure Digital - SD |
| Connector Type | Connector and Ejector |
| Contact Finish | Gold |
| Features | Switch, Board Guide |
| Height Above Board [z] | 2.9 mm |
| Height Above Board [z] | 0.114 " |
| Insertion, Removal Method | Push Out, Push In |
| Mounting Feature | Reverse - Bottom |
| Mounting Type | Surface Mount, Right Angle |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
DM1B Series
12 (9 + 3) Position Card Connector Secure Digital - SD Surface Mount, Right Angle Gold
