682-015-113R531

Obsolete

MH Connectors

IP66 15 / .318" -531 ROHS COMPLIANT: YES

Search across all available documentation for this part.

Obsolete

MH Connectors

IP66 15 / .318" -531 ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	682-015-113R531

Backset Spacing	8.08 mm
Backset Spacing	0.318 "
Color	Black
Connector Style	D-Sub
Connector Type	Plug, Male Pins
Contact Finish	Gold
Contact Finish Thickness	Flash
Contact Material	Brass
Contact Type	Signal
Current Rating (Amps)	5 A
Dielectric Material	Polyamide (PA9T), Nylon 9T
Features	Grounding Indents, Board Lock
Flange Feature	Housing/Shell (4-40)
Ingress Protection	IP66
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Right Angle, Panel Mount
Number of Positions	15
Number of Rows	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Shell Material, Finish	Nickel Plated, Steel
Shell Size, Connector Layout	2
Termination	Solder

Part	Contact Finish	Contact Finish Thickness	Features	Material Flammability Rating	Shell Size, Connector Layout	Backset Spacing	Backset Spacing	Color	Flange Feature	Contact Material	Termination	Number of Rows	Number of Positions	Dielectric Material	Connector Type	Shell Material, Finish	Mounting Type	Connector Style	Current Rating (Amps)	Ingress Protection	Operating Temperature [Max]	Operating Temperature [Min]	Contact Type
MH Connectors 682-015-113R531	Gold	Flash	Board Lock Grounding Indents	UL94 V-0	2	8.08 mm	0.318 "	Black	Housing/Shell (4-40)	Brass	Solder	2	15	Polyamide (PA9T) Nylon 9T	Male Pins Plug	Nickel Plated Steel	Panel Mount Right Angle Through Hole	D-Sub	5 A	IP66	105 ░C	-55 °C	Signal

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

15 Position D-Sub Plug, Male Pins Connector
