Technical Specifications
Parameters and characteristics for this part
| Specification | 0327030.YX2S |
|---|---|
| Color | Green |
| Current Rating (Amps) | 30 A |
| Fuse Type | Automotive |
| Melting I˛t | 1028 |
| Mounting Type | Requires Holder |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Blade, Micro |
| Size / Dimension [x] | 0.358 in |
| Size / Dimension [x] | 9.1 mm |
| Size / Dimension [y] | 0.15 " |
| Size / Dimension [y] | 3.8 mm |
| Size / Dimension [z] | 7.9 mm |
| Size / Dimension [z] | 0.311 " |
| Voltage Rating - DC | 32 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
0327030.YX2S Series
This 30 A MICRO2TM blade fuse has proven its reliability in polluted, humid, and high-temperature environments. Its subminiature design makes the MICRO2 a go-to option for automakers looking to reduce vehicle weight without sacrificing circuit protection.
