ALS36H103D3C050

Active

KEMET

CAP ALUM 10000UF 50V SCREW CHAS

Search across all available documentation for this part.

Active

KEMET

CAP ALUM 10000UF 50V SCREW CHAS

Technical Specifications

Parameters and characteristics for this part

Specification	ALS36H103D3C050

Applications	General Purpose
Capacitance	10000 µF
ESR (Equivalent Series Resistance)	24 mOhm
Height - Seated (Max) [Max] [z]	3.125 in
Height - Seated (Max) [Max] [z]	79.38 mm
Lead Spacing	0.5 in
Lead Spacing	12.7 mm
Lifetime @ Temp.	11000 Hrs
Mounting Type	Chassis Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can - Screw Terminals
Polarization	Polar
Ripple Current @ High Frequency	15.6 A
Ripple Current @ Low Frequency	11.7 A
Size / Dimension [diameter]	1.375 "
Size / Dimension [diameter]	34.93 mm
Tolerance [Max]	30 %
Tolerance [Min]	-10 %
Voltage - Rated	50 VDC

Part	Capacitance	Lifetime @ Temp.	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Ripple Current @ Low Frequency	Voltage - Rated	Lead Spacing	Lead Spacing	ESR (Equivalent Series Resistance)	Size / Dimension [diameter]	Size / Dimension [diameter]	Package / Case	Tolerance [Min]	Tolerance [Max]	Applications	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Ripple Current @ High Frequency	Polarization
KEMET ALS36H103D3C050	10000 µF	11000 Hrs	85 °C	-40 °C	Chassis Mount	11.7 A	50 VDC	0.5 in	12.7 mm	24 mOhm	1.375 "	34.93 mm	Radial Can - Screw Terminals	-10 %	30 %	General Purpose	3.125 in	79.38 mm	15.6 A	Polar

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10000 µF 50 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 24mOhm @ 120Hz 11000 Hrs @ 85°C
