3382-4PG-530

Active

Conxall/Switchcraft

CONN PLUG MALE 4P GOLD SLDR CUP

Search across all available documentation for this part.

Active

Conxall/Switchcraft

CONN PLUG MALE 4P GOLD SLDR CUP

Technical Specifications

Parameters and characteristics for this part

Part	Orientation	Voltage Rating	Color	Number of Positions	Features	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Cable Opening [custom]	Cable Opening [custom]	Backshell Material, Plating	Contact Finish - Mating	Fastening Type	Mounting Type	Connector Type	Ingress Protection	Primary Material	Shielding	Cable Opening [Min] [diameter]	Cable Opening [Max] [diameter]	Cable Opening [Min] [diameter]	Cable Opening [Max] [diameter]	Cable Opening [Max] [diameter]
Conxall/Switchcraft 3382-4PG-515	Keyed	600 V	Black	4	Backshell Cable Clamp	-40 °C	115 °C	Brass	0.15 in 0.17 in	3.81 mm 4.32 mm	Nylon Polyamide (PA)	Gold	Bayonet Lock	Free Hanging (In-Line)	Male Pins Plug	Weathertight	Plastic	Unshielded
Conxall/Switchcraft 3382-4PG-324	Keyed	600 V	Black	4	Backshell	-40 °C	115 °C	Brass			Nylon Polyamide (PA)	Gold	Bayonet Lock	Free Hanging (In-Line)	Male Pins Plug	Weathertight	Plastic	Unshielded	0.24 in	6.86 mm	6.1 mm	0.27 in
Conxall/Switchcraft 3382-4PG-528	Keyed	600 V	Black	4	Backshell Cable Clamp	-40 °C	115 °C	Brass			Nylon Polyamide (PA)	Gold	Bayonet Lock	Free Hanging (In-Line)	Male Pins Plug	Weathertight	Plastic	Unshielded	0.28 in	7.37 mm	7.11 mm	0.29 in
Conxall/Switchcraft 3382-4PG-530	Keyed	600 V	Black	4	Backshell Cable Clamp	-40 °C	115 °C	Brass			Nylon Polyamide (PA)	Gold	Bayonet Lock	Free Hanging (In-Line)	Male Pins Plug	Weathertight	Plastic	Unshielded	0.3 in		7.62 mm	0.32 in	8.13 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Circular Connector Plug, Male Pins Solder Cup
