GSC120C
ActiveMacromatic Industrial Controls
RELAY GEN PURPOSE SPDT 6A 120V
Deep-Dive with AI
Search across all available documentation for this part.
GSC120C
ActiveMacromatic Industrial Controls
RELAY GEN PURPOSE SPDT 6A 120V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | GSC120C |
|---|---|
| Coil Type | Non Latching |
| Coil Voltage | 120 VAC, 120 VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 6 A |
| Features | Lighted Indicator |
| Mounting Type | DIN Rail |
| Must Operate Voltage | 108 VAC |
| Operating Temperature [Max] | 55 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Switching Voltage [Max] | 30 VDC, 250 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 10 | $ 16.94 | |
Description
General part information
GSC12 Series
General Purpose Relay SPDT (1 Form C) 120VAC/DC Coil DIN Rail
Documents
Technical documentation and resources
No documents available
