SRP4020-4R7M

Obsolete

Bourns Inc.

FIXED IND 4.7UH 2.7A 75 MOHM SMD

Search across all available documentation for this part.

Obsolete

Bourns Inc.

FIXED IND 4.7UH 2.7A 75 MOHM SMD

Technical Specifications

Parameters and characteristics for this part

Part	Current - Saturation (Isat)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Material - Core	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Tolerance	Type	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Mounting Type	Inductance Frequency - Test	Shielding	Inductance	Package / Case	DC Resistance (DCR) [Max]	DC Resistance (DCR)
Bourns Inc. SRP4020-3R3M	4.3 A	4 mm	0.189 "	0.157 in	4.8 mm	Iron	2 mm	0.079 in	20 %	Molded	-55 °C	125 °C	3.3 A	Surface Mount	100 kHz	Shielded	3.3 µH	Nonstandard
Bourns Inc. SRP4020-4R7M	4 A	4 mm	0.189 "	0.157 in	4.8 mm	Iron	2 mm	0.079 in	20 %	Molded	-55 °C	125 °C	2.7 A	Surface Mount	100 kHz	Shielded	4.7 ÁH	Nonstandard	75 mOhm
Bourns Inc. SRP4020-1R2M	5 A	4 mm	0.189 "	0.157 in	4.8 mm	Iron	2 mm	0.079 in	20 %	Molded	-55 °C	125 °C	5 A	Surface Mount	100 kHz	Shielded	1.2 µH	Nonstandard
Bourns Inc. SRP4020-R88M	6.5 A	4 mm	0.189 "	0.157 in	4.8 mm	Iron	2 mm	0.079 in	20 %	Molded	-55 °C	125 °C	6 A	Surface Mount	100 kHz	Shielded	880 nH	Nonstandard		18 mOhm
Bourns Inc. SRP4020-R56M	8 A	4 mm	0.189 "	0.157 in	4.8 mm	Iron	2 mm	0.079 in	20 %	Molded	-55 °C	125 °C	7 A	Surface Mount	100 kHz	Shielded	560 nH	Nonstandard	14.7 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

4.7 µH Shielded Molded Inductor 2.7 A 75mOhm Max Nonstandard
