A3U-TMR-A2C-M

Active

Omron Electronics Inc-EMC Div

SWITCH PUSHBUTTON DPDT 0.1A 30V

Search across all available documentation for this part.

Active

Omron Electronics Inc-EMC Div

SWITCH PUSHBUTTON DPDT 0.1A 30V

Technical Specifications

Parameters and characteristics for this part

Specification	A3U-TMR-A2C-M

Actuator Marking	No Marking
Actuator Type	Flush, Button, Round
Circuit	DPDT
Color - Actuator/Cap	Clear (Red Filter/Diffuser)
Current Rating (Amps)	100 mA
Electrical Life	200000 Cycles
Ingress Protection	IP40
Mechanical Life	1000000 Cycles
Mounting Type	Panel Mount, Front
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Panel Cutout Dimensions [diameter]	25.2 mm
Switch Function	On-Mom
Termination Style	Connector
Type	Standard
Voltage Rating - DC	30 V

Part	Mounting Type	Termination Style	Voltage Rating - DC	Ingress Protection	Color - Actuator/Cap	Switch Function	Operating Temperature [Min]	Operating Temperature [Max]	Panel Cutout Dimensions [diameter]	Actuator Type	Type	Actuator Marking	Current Rating (Amps)	Mechanical Life	Electrical Life	Circuit
Omron Electronics Inc-EMC Div A3U-TMR-A1C-5M	Panel Mount Front	Connector	30 V	IP65	Clear (Red Filter/Diffuser)	On-Mom	-20 C	70 °C	25.2 mm	Button Flush Round	Standard	No Marking	100 mA	1000000 Cycles	200000 Cycles	SPDT
Omron Electronics Inc-EMC Div A3U-TMR-A1C-M	Panel Mount Front	Connector	30 V	IP40	Clear (Red Filter/Diffuser)	On-Mom	-20 C	70 °C	25.2 mm	Button Flush Round	Standard	No Marking	100 mA	1000000 Cycles	200000 Cycles	SPDT
Omron Electronics Inc-EMC Div A3U-TMR-A2C-M	Panel Mount Front	Connector	30 V	IP40	Clear (Red Filter/Diffuser)	On-Mom	-20 C	70 °C	25.2 mm	Button Flush Round	Standard	No Marking	100 mA	1000000 Cycles	200000 Cycles	DPDT

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pushbutton Switch DPDT Standard Panel Mount, Front
