671-009-103L001

Obsolete

MH Connectors

671-009-103L001 ROHS COMPLIANT: YES

Search across all available documentation for this part.

Obsolete

MH Connectors

671-009-103L001 ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	671-009-103L001

Color	Black
Connector Style	D-Sub
Connector Type	Plug, Male Pins
Contact Finish	Gold
Contact Finish Thickness	Flash
Contact Form	Stamped
Contact Material	Brass
Contact Type	Signal
Current Rating (Amps)	5 A
Dielectric Material	Polybutylene Terephthalate (PBT)
Features	Grounding Indents
Flange Feature	Housing/Shell (Unthreaded)
Ingress Protection	IP66
Material Flammability Rating	UL94 V-0
Number of Positions	9
Number of Rows	2
Shell Material, Finish	Nickel Plated, Steel
Shell Size, Connector Layout [custom]	DE, E
Shell Size, Connector Layout [custom]	1
Wire Gauge [Max]	28 AWG
Wire Gauge [Min]	20 AWG

Part	Termination	Shell Material, Finish	Contact Finish	Contact Form	Contact Material	Number of Positions	Connector Style	Dielectric Material	Mounting Type	Features	Number of Rows	Connector Type	Contact Type	Flange Feature	Color	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Material Flammability Rating	Current Rating (Amps)	Contact Finish Thickness	Ingress Protection	Wire Gauge [Min]	Wire Gauge [Max]
MH Connectors 671-009-113R031	Solder	Nickel Plated Steel	Gold	Stamped	Brass	9	D-Sub	Polyamide (PA9T) Nylon 9T	Panel Mount Through Hole	Grounding Indents	2	Male Pins Plug	Signal	4-40	Black	DE E	1	UL94 V-0	5 A	Flash	IP66
MH Connectors 671-009-103L001		Nickel Plated Steel	Gold	Stamped	Brass	9	D-Sub	Polybutylene Terephthalate (PBT)		Grounding Indents	2	Male Pins Plug	Signal	Housing/Shell (Unthreaded)	Black	DE E	1	UL94 V-0	5 A	Flash	IP66	20 AWG	28 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

9 Position D-Sub Plug, Male Pins Connector
