MT4N-DA-EN

Active

AUTONICS

DIGITAL METER, DC CURRENT, MT4N SERIES, 4 DIGITS, 12 VAC TO 24 VAC, NO OUTPUT

Search across all available documentation for this part.

Active

AUTONICS

DIGITAL METER, DC CURRENT, MT4N SERIES, 4 DIGITS, 12 VAC TO 24 VAC, NO OUTPUT

Technical Specifications

Parameters and characteristics for this part

Specification	MT4N-DA-EN

Display Characters - Height [z]	9 mm
Display Characters - Height [z]	0.354 "
Display Type	LCD - Red Characters, Backlight
Measuring Range [Max]	500 mA
Measuring Range [Min]	0 A
Measuring Type	Current
Number of Characters Per Row	4
Panel Cutout Dimensions [x]	45 mm
Panel Cutout Dimensions [y]	22.2 mm
Termination Style	Screw Terminal
Type	Ammeter
Voltage - Supply [Max]	24 VAC
Voltage - Supply [Min]	12 VAC

Part	Measuring Type	Type	Display Characters - Height [z]	Display Characters - Height [z]	Display Type	Number of Characters Per Row	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Measuring Range [Max]	Voltage - Supply [Max]	Voltage - Supply [Min]	Termination Style	Output Type
AUTONICS MT4N-DA-EN	Current	Ammeter	9 mm	0.354 "	LCD - Red Characters Backlight	4	22.2 mm	45 mm	500 mA	24 VAC	12 VAC	Screw Terminal
AUTONICS MT4N-DA-E0	Current	Ammeter	9 mm	0.354 "	LCD - Red Characters Backlight	4	22.2 mm	45 mm	500 mA	24 VAC	12 VAC	Screw Terminal	Relay (2)
AUTONICS MT4N-DA-E2	Current	Ammeter	9 mm	0.354 "	LCD - Red Characters Backlight	4	22.2 mm	45 mm	500 mA	24 VAC	12 VAC	Screw Terminal	Solid State

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 166.00
Newark	Each	1	$ 166.00

General part information

Ammeter LCD - Red Characters, Backlight Display Panel Mount
