1218440-2

Active

TE Connectivity Aerospace, Defense and Marine

CONN D-SUB PLUG 15POS R/A SLDR

Search across all available documentation for this part.

Active

TE Connectivity Aerospace, Defense and Marine

CONN D-SUB PLUG 15POS R/A SLDR

Technical Specifications

Parameters and characteristics for this part

Specification	1218440-2

Backset Spacing	8.08 mm
Backset Spacing	0.318 "
Color	Black
Connector Style	D-Sub
Connector Type	Plug, Male Pins
Contact Finish	Gold
Contact Finish Thickness	10 Áin
Contact Finish Thickness	0.25 Ám
Contact Material	Brass
Contact Type	Signal
Current Rating (Amps)	5 A
Flange Feature	Housing/Shell (Unthreaded)
Mounting Type	Through Hole, Right Angle
Number of Positions	15
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Shell Material, Finish [custom]	Steel
Shell Material, Finish [custom]	Cadmium Plated
Shell Size, Connector Layout	2
Termination	Solder

Part	Number of Positions	Flange Feature	Shell Material, Finish [custom]	Shell Material, Finish [custom]	Termination	Connector Style	Contact Type	Backset Spacing	Backset Spacing	Color	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Number of Rows	Mounting Type	Contact Material	Connector Type	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Shell Size, Connector Layout	Shell Size, Connector Layout
TE Connectivity Aerospace, Defense and Marine 1218440-6	9	Housing/Shell (Unthreaded)	Steel	Cadmium Plated	Solder	D-Sub	Signal	8.08 mm	0.318 "	Black	Gold	10 Áin	0.25 Ám	2	Through Hole Right Angle	Brass	Male Pins Plug	DE E	1
TE Connectivity Aerospace, Defense and Marine 1218440-4	37	Housing/Shell (Unthreaded)	Steel	Cadmium Plated	Solder	D-Sub	Signal	8.08 mm	0.318 "	Black	Gold	10 Áin	0.25 Ám	2	Through Hole Right Angle	Brass	Male Pins Plug			-55 °C	125 °C	5 A	4 (DC C)
TE Connectivity Aerospace, Defense and Marine 1218440-2	15	Housing/Shell (Unthreaded)	Steel	Cadmium Plated	Solder	D-Sub	Signal	8.08 mm	0.318 "	Black	Gold	10 Áin	0.25 Ám	2	Through Hole Right Angle	Brass	Male Pins Plug			-55 °C	125 °C	5 A		2
TE Connectivity Aerospace, Defense and Marine 1218440-5	50	Housing/Shell (Unthreaded)	Steel	Cadmium Plated	Solder	D-Sub	Signal	8.08 mm	0.318 "	Black	Gold	10 Áin	0.25 Ám	3	Through Hole Right Angle	Brass	Male Pins Plug			-55 °C	125 °C	5 A		5

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	156	$ 32.07

General part information

15 Position D-Sub Plug, Male Pins Connector
